Hardware Specification:

◎  2.8” TFT

◎  Support doo-bell key

◎  12V DC input，rated current 3A

◎  High speed RS485 support(slave)

◎  100M Ethernet support

◎  5V relay alerting signal output

◎  5V relay door lock signal

◎  Door magnetic detection input（opto-isolator）.

◎  Wiegand 26/34 output

◎  Wiegand input（opto-isolator），12VDC output MAX 500mA，with Over-current protection design.

◎  5ppm temperature compensation clock

◎  Tamper alarm

◎  Hardware reset watch dog support

◎  Reset button

◎  USB HOST/Device support(OTG), U disk support

◎  16MB Industrial level RAM

◎  8MB storage Flash.

◎  8ohm 0.5W speaker output

◎  500DPI optics fingerprint input

◎  Optional ID/IC  card support

◎  Optional TF card，Bulk-storage memory(Optional)

◎  Bi-color red, green indicator light

◎  Starting up power on(Optional，default is starting up power on)

◎  Operating temperature,-20℃ ~ 70℃.

◎  Wall mounting type，collocation with metal plate, enclosure 3MMthicken design

Function:

◎  Door control access function. Time, group, combination lock setting. Complex access control logic support.

◎  Time attendance function. Auto report, department personal management.

◎  Support card, password, fingerprint authentication

◎  Off-line working, Also can realize complex access network monitoring

◎  Real time fingerprint image

◎  Verification speed <1s.

◎  FAR < 0.001%.

◎  FRR < 0.01%.

◎  Capacity 800pcs

◎  Record capacity 100,000pcs.

◎  TCP/IP , RS485 networking.

Feature：

◎  Large size TFT, Friendly human-computer interaction，Enclosure adopt with consolidation handling, solid and reliable.

◎  Strong expandability，can expand IC/ID, Wiegand input and output

◎  Suit for complex environment

◎  Anti-thunder for input and output. Opto-isolator, fuse wire, good safety performance

◎  Hardware watchdog, ensure always work.
